Motor Control Centers (MCC) & VFD Racks

High-Power Motor Control Lineups, Solid State Starters, & PLC Links

Centralize your industrial motor controls. We assemble modular motor control centers, integrate variable frequency drives (VFDs) up to 1000HP, wire soft starters to avoid mechanical inrush shocks, and connect MCC assemblies to PLC pipelines.

Core Capabilities

Modular NEMA Class II MCC assemblies with draw-out starter units.

Heavy-duty Variable Frequency Drives (VFD) and harmonic line filters.

Solid-state soft starters for torque surge control on heavy pumps.

Devicenet, Profibus, or Ethernet/IP communication module drops.

Architecture Summary

Power buses feed modular starter drawers, where contacts, thermal overloads, and VFD modules regulate speed and current spikes during mechanical loads.

Asset // Conceptual 3D Model

Motor Control Centers (MCC) & VFD Racks concept render

Model R-019

Industrial Schematic Blueprint

Generated CAD-grade conceptual mapping showing spatial tolerances and sensor grid alignment.

Asset // Software Interface

Motor Control Centers (MCC) & VFD Racks dashboard interface

Active Feed

HMI Operations Dashboard

High-fidelity software mock interface rendering continuous log outputs and warning logic.

Tech Specifications

Busbar Ratings600A to 3000A Horizontal copper power buses

Starter ClassesNEMA Size 1 to Size 6 Combination Starters

VFD Harmonics18-Pulse VFD topologies / Active Front End rectifiers

Control Voltage120VAC isolated control loops / 24VDC PLC loops

Division Certifications

UL 845 Motor Control CentersNEMA ICS 18 MCC GuidelinesNEC Article 430 Motors & Controllers
