Transformer Testing & Preventive Maintenance

Dissolved Gas Analysis (DGA), Insulation Resistance, & Oil Filtration

Protect utility and industrial substation transformers from catastrophic faults. Our testing technicians carry out diagnostic sweeps, execute oil sampling, measure winding ratios, and perform online filtration loops to scrub carbon and moisture from dielectric fluids.

Core Capabilities

Insulation Power Factor testing and turns-ratio verification (TTR).

Dissolved Gas Analysis (DGA) for tracking internal arc indicators.

Transformer oil filtration, dehydration, and degassing.

Winding resistance and sweep frequency response analysis (SFRA).

Architecture Summary

Diagnostic instruments sweep frequency responses and analyze fluid compositions, comparing baseline curves to detect winding displacement or insulation deterioration before faults trigger.

Asset // Conceptual 3D Model

Transformer Testing & Preventive Maintenance concept render

Model R-019

Industrial Schematic Blueprint

Generated CAD-grade conceptual mapping showing spatial tolerances and sensor grid alignment.

Asset // Software Interface

Transformer Testing & Preventive Maintenance dashboard interface

Active Feed

HMI Operations Dashboard

High-fidelity software mock interface rendering continuous log outputs and warning logic.

Tech Specifications

Test EquipmentDoble M4100 / Megger TTR / Kelman DGA

Insulation LimitsUp to 10kV insulation resistance testing

Oil StandardsASTM D877 / D1816 dielectric breakdown checks

Analysis PeriodAnnual diagnostic sweeps & continuous DGA logs

Division Certifications

IEEE C57.104 Gas AnalysisNETA MTS Maintenance TestingASTM D3612 Oil Gas Chromatography
